Schema: Pro Tables

This page documents every table created by BuddyNextPro\Core\Installer, grouped by domain, with a column reference for each. It is for developers querying or extending Pro data. The same Scale-Contract rules that shape Free tables apply here - denormalized aggregates, an index for every WHERE column, and a (created_at, id) cursor key for paginated lists. See Data Model Overview for the naming convention and the master table index, and Schema: Core Tables for the Free tables.

Contract: ownership and the Free/Pro boundary

Pro tables use the same bn_ prefix as Free (there is no bnpro_ prefix). Pro’s Installer creates only Pro-owned tables and never re-creates a Free table. Two boundary rules govern this surface:

1. Pro never creates or modifies Free tables. When a Pro feature needs an extra column, it is added to a Pro-owned table, or - for additive columns on Pro tables - through Installer::maybe_alter_tables() behind an INFORMATION_SCHEMA guard so re-runs are no-ops. The membership tier columns (price, currency, billing_type, billing_interval, trial_days, is_free, status, entitlements) are back-filled this way onto bn_membership_tiers.
2. bn_mod_appeals does not exist. The Pro moderation spec named an appeals table bn_mod_appeals, but Pro reuses Free’s bn_appeals for the appeal workflow. The two names are the same logical table; Pro does not duplicate it.

Note: The authoritative list of what Pro creates is the schema() method in BuddyNextPro\Core\Installer (schema_membership_extension() + schema_core()), which creates 18 Pro-owned tables. This page follows the Installer, which is the only authoritative list of what Pro creates. Note it also touches Free’s bn_posts and WPMediaVerse’s mvs_* tables that Pro reads but does not own).

Membership

The revenue layer. Tier definitions, per-user subscriptions, gateway price mapping, and the billing-support tables (invoices, coupons, tax rules).

bn_membership_tiers

Tier definitions. The base table is created by schema_core(); the pricing/billing columns are added by maybe_alter_tables() on upgrade.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
slug	VARCHAR(100)	Unique key slug
name	VARCHAR(255)	Display name
description	TEXT	Nullable
sort_order	INT	Default 0; indexed (sort)
points_price	BIGINT(20) UNSIGNED	Default 0. Gamification points price. Base column in schema_core(); also back-filled by maybe_alter_tables() for older installs.
price	DECIMAL(10,2)	Default 0 (added via ALTER)
currency	CHAR(3)	Default USD (added via ALTER)
billing_type	ENUM(‘recurring’,‘one_time’)	Default recurring (added via ALTER)
billing_interval	ENUM(‘month’,‘year’,‘once’)	Default month (added via ALTER)
trial_days	INT	Default 0 (added via ALTER)
is_free	TINYINT(1)	Default 0 (added via ALTER)
status	ENUM(‘active’,‘inactive’,‘archived’)	Default inactive (added/widened via ALTER)
entitlements	LONGTEXT	JSON entitlement payload, nullable (added via ALTER)
created_at	DATETIME	Default CURRENT_TIMESTAMP

Keys: PRIMARY (id), UNIQUE slug (slug), KEY sort (sort_order).

bn_subscriptions

Per-user subscription rows linked to a tier and a gateway. The unique external_id lets the gateway webhook upsert idempotently.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
user_id	BIGINT(20) UNSIGNED	Subscriber
tier_id	BIGINT(20) UNSIGNED	References bn_membership_tiers.id
status	ENUM(‘active’,‘expired’,‘cancelled’,‘past_due’,‘trialing’)	Default active
source	VARCHAR(32)	Default manual. Gateway/source slug (e.g. manual, stripe, paypal) - a free-text column, not an enum.
started_at	DATETIME	Default CURRENT_TIMESTAMP
expires_at	DATETIME	Nullable; indexed (expires)
external_id	VARCHAR(255)	Gateway subscription ID, nullable; unique
reminder_sent_days	SMALLINT UNSIGNED	Added 1.1.5. The smallest reminder offset already sent for this subscription, nullable. Makes the renewal-reminder sweep idempotent without a join table.
created_at	DATETIME	Default CURRENT_TIMESTAMP
updated_at	DATETIME	ON UPDATE CURRENT_TIMESTAMP

Keys: PRIMARY (id), UNIQUE external_id (external_id), KEY user_status (user_id, status), KEY tier_status (tier_id, status), KEY expires (expires_at).

bn_plan_gateway_map

One row per (plan, gateway, mode) triple. Caches the provider’s price ID so repeat checkouts skip the lazy-provision round-trip.

Column	Type	Notes
id	BIGINT UNSIGNED	Primary key, auto-increment
plan_id	BIGINT UNSIGNED	References a tier
gateway	VARCHAR(40)	Gateway slug (e.g. stripe)
mode	VARCHAR(20)	live or test
provider_price_id	VARCHAR(191)	Gateway price ID, nullable
created_at	DATETIME	Default CURRENT_TIMESTAMP
updated_at	DATETIME	ON UPDATE CURRENT_TIMESTAMP

Keys: PRIMARY (id), UNIQUE plan_gateway_mode (plan_id, gateway, mode).

bn_invoices

Purchase receipts. The meta JSON blob carries line items and billing address for future PDF generation.

Column	Type	Notes
id	BIGINT UNSIGNED	Primary key, auto-increment
user_id	BIGINT UNSIGNED	Indexed (user_id)
plan_id	BIGINT UNSIGNED	Indexed (plan_id)
gateway	VARCHAR(40)	Gateway slug
amount	DECIMAL(10,2)	Default 0
tax	DECIMAL(10,2)	Default 0
discount	DECIMAL(10,2)	Default 0
total	DECIMAL(10,2)	Default 0
currency	CHAR(3)	Default USD
status	VARCHAR(20)	Default paid
number	VARCHAR(50)	Human invoice number, nullable
refunded	DECIMAL(10,2)	Added 1.1.5. Cumulative amount refunded against this order, default 0. A partial refund increments it; the guard is refunded + amount <= total.
created_at	DATETIME	Default CURRENT_TIMESTAMP
meta	LONGTEXT	JSON line items + address, nullable

Keys: PRIMARY (id), KEY user_id (user_id), KEY plan_id (plan_id), KEY created_at (created_at), KEY status (status).

bn_coupons

Discount codes. applies_to is a JSON array of plan IDs (null means all plans).

Column	Type	Notes
id	BIGINT UNSIGNED	Primary key, auto-increment
code	VARCHAR(60)	Unique
type	ENUM(‘percent’,‘fixed’)	Default percent
value	DECIMAL(10,2)	Default 0
applies_to	LONGTEXT	JSON plan-ID array, nullable
max_redemptions	INT	Default 0 (0 = unlimited)
redeemed	INT	Default 0
expires_at	DATETIME	Nullable
active	TINYINT(1)	Default 1
created_at	DATETIME	Default CURRENT_TIMESTAMP

Keys: PRIMARY (id), UNIQUE code (code).

bn_tax_rules

Local tax-rule fallback used when the active gateway provides no native tax calculation.

Column	Type	Notes
id	BIGINT UNSIGNED	Primary key, auto-increment
region	VARCHAR(100)	Region identifier
rate	DECIMAL(6,3)	Default 0
inclusive	TINYINT(1)	Default 0
label	VARCHAR(100)	Display label, nullable
created_at	DATETIME	Default CURRENT_TIMESTAMP

Keys: PRIMARY (id).

AI

Behavioral signals for ranked feed and cached embeddings for semantic search.

bn_ai_signals

One row per engagement event, written by SignalsCollector. The signal_type ENUM was widened from the original set to include view and dwell.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
user_id	BIGINT(20) UNSIGNED	The actor who generated the signal
signal_type	ENUM(‘view’,‘react’,‘comment’,‘follow’,‘bookmark’,‘dwell’)	Per-type weight applied at write
object_type	VARCHAR(32)	Target object type
object_id	BIGINT(20) UNSIGNED	Target object ID
weight	FLOAT	Default 1.0
created_at	DATETIME	Default CURRENT_TIMESTAMP

Keys: PRIMARY (id), KEY user_signal_date (user_id, signal_type, created_at), KEY object (object_type, object_id), KEY created (created_at).

bn_ai_embeddings

Cached vector embedding per object for semantic search. The unique (object_type, object_id) key makes indexing an upsert; text_hash detects content changes so unchanged objects are not re-embedded.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
object_type	VARCHAR(32)	Object type (e.g. post)
object_id	BIGINT(20) UNSIGNED	Object ID
embedding	LONGTEXT	Serialized vector
text_hash	CHAR(64)	Hash of the embedded text
created_at	DATETIME	Default CURRENT_TIMESTAMP

Keys: PRIMARY (id), UNIQUE uniq_object (object_type, object_id).

Push

Mobile push device registry.

bn_push_tokens

FCM / APNs device tokens per user. Registration is an UPSERT on the unique token column (updates last_seen_at and platform on conflict); the push client deletes tokens that return 404/410.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
user_id	BIGINT(20) UNSIGNED	Owner; indexed (idx_user)
platform	VARCHAR(16)	Default web (web / ios / android)
token	VARCHAR(512)	Device token; unique on a 255-char prefix
device_label	VARCHAR(128)	Friendly device name, nullable
last_seen_at	DATETIME	Default CURRENT_TIMESTAMP
created_at	DATETIME	Default CURRENT_TIMESTAMP

Keys: PRIMARY (id), UNIQUE uniq_token (token(255)), KEY idx_user (user_id).

Analytics

bn_analytics_events

Raw analytics event stream written by AnalyticsCollector (which listens to 25+ Free actions). The query API (AnalyticsService) aggregates DAU/WAU/MAU, top content, top members, and space health from this table.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
event_type	VARCHAR(64)	Event name
actor_id	BIGINT(20) UNSIGNED	Acting user, nullable
target_type	VARCHAR(32)	Target object type, nullable
target_id	BIGINT(20) UNSIGNED	Target object ID, nullable
properties	JSON	Arbitrary event payload, nullable
created_at	DATETIME	Default CURRENT_TIMESTAMP

Keys: PRIMARY (id), KEY event_date (event_type, created_at), KEY actor_date (actor_id, created_at), KEY target (target_type, target_id), KEY created (created_at).

Email

Broadcast campaigns and drip sequences, each split into a definition table and a per-recipient/per-enrollment table.

bn_email_campaigns

Broadcast campaign definitions. segment_filter is JSON describing the audience segment.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
name	VARCHAR(255)	Internal name
subject	VARCHAR(255)	Email subject
body_html	LONGTEXT	HTML body
status	ENUM(‘draft’,‘scheduled’,‘sending’,‘sent’)	Default draft
segment_filter	JSON	Audience segment, nullable
scheduled_at	DATETIME	Nullable
sent_at	DATETIME	Nullable
created_by	BIGINT(20) UNSIGNED	Author; indexed (created_by)
created_at	DATETIME	Default CURRENT_TIMESTAMP
updated_at	DATETIME	ON UPDATE CURRENT_TIMESTAMP

Keys: PRIMARY (id), KEY status_date (status, scheduled_at), KEY created_by (created_by).

bn_campaign_recipients

Per-recipient delivery and engagement tracking. The unique (campaign_id, user_id) key prevents double-send.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
campaign_id	BIGINT(20) UNSIGNED	References bn_email_campaigns.id
user_id	BIGINT(20) UNSIGNED	Recipient
status	ENUM(‘queued’,‘sent’,‘opened’,‘clicked’,‘bounced’,‘unsubscribed’)	Default queued
sent_at	DATETIME	Nullable
opened_at	DATETIME	Nullable
clicked_at	DATETIME	Nullable

Keys: PRIMARY (id), UNIQUE campaign_user (campaign_id, user_id), KEY campaign_status (campaign_id, status), KEY user_campaigns (user_id).

bn_drip_sequences

Drip sequence definitions. steps is a JSON array of step objects (delay_days, subject, body_html, etc.). trigger is a reserved word, quoted with backticks in the schema.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
name	VARCHAR(255)	Sequence name
trigger	ENUM(‘user_register’,‘onboarding_completed’,‘manual’)	Default manual
enabled	TINYINT(1)	Default 1; indexed (enabled)
steps	LONGTEXT	JSON step array, nullable
created_at	DATETIME	Default CURRENT_TIMESTAMP
updated_at	DATETIME	ON UPDATE CURRENT_TIMESTAMP

Keys: PRIMARY (id), KEY enabled (enabled).

bn_drip_enrollments

Per-user enrollment in a drip sequence, with the current step pointer. Unique (sequence_id, user_id) prevents double-enrollment.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
sequence_id	BIGINT(20) UNSIGNED	References bn_drip_sequences.id
user_id	BIGINT(20) UNSIGNED	Enrolled user
current_step	SMALLINT UNSIGNED	Default 0
status	ENUM(‘active’,‘completed’,‘unsubscribed’)	Default active
enrolled_at	DATETIME	Default CURRENT_TIMESTAMP
last_step_at	DATETIME	Nullable
completed_at	DATETIME	Nullable

Keys: PRIMARY (id), UNIQUE sequence_user (sequence_id, user_id), KEY sequence_status (sequence_id, status), KEY user_enrollments (user_id).

Moderation

bn_mod_rules

Auto-moderation rule definitions. config is JSON whose shape depends on rule_type.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
name	VARCHAR(255)	Rule name
rule_type	ENUM(‘keyword_block’,‘link_block’,‘rate_limit’,‘threshold_remove’)	Rule kind
config	JSON	Rule parameters
enabled	TINYINT(1)	Default 1
priority	INT	Default 0
created_at	DATETIME	Default CURRENT_TIMESTAMP
updated_at	DATETIME	ON UPDATE CURRENT_TIMESTAMP

Keys: PRIMARY (id), KEY enabled_priority (enabled, priority), KEY rule_type (rule_type).

Note: Auto-moderation appeals are not stored in a Pro table. Pro reuses Free’s bn_appeals (see the boundary contract above). There is no bn_mod_appeals.

Labels

Custom member labels and their assignments. Pro seeds three starter labels (Verified, Expert, Staff) on install.

bn_member_labels

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
slug	VARCHAR(100)	Unique
name	VARCHAR(255)	Display name
color	VARCHAR(7)	Hex color; default #0073aa
icon	VARCHAR(100)	Icon slug, nullable
sort_order	INT	Default 0; indexed (sort)
created_at	DATETIME	Default CURRENT_TIMESTAMP

Keys: PRIMARY (id), UNIQUE slug (slug), KEY sort (sort_order).

bn_member_label_assignments

Unique (user_id, label_id) prevents assigning the same label twice.

Column	Type	Notes
id	BIGINT(20) UNSIGNED	Primary key, auto-increment
user_id	BIGINT(20) UNSIGNED	Labeled user
label_id	BIGINT(20) UNSIGNED	References bn_member_labels.id
assigned_by	BIGINT(20) UNSIGNED	Admin who assigned; indexed (assigned_by)
assigned_at	DATETIME	Default CURRENT_TIMESTAMP

Keys: PRIMARY (id), UNIQUE user_label (user_id, label_id), KEY label_users (label_id), KEY assigned_by (assigned_by).

Search

bn_saved_searches

Per-user saved search definitions (capped at 50 per user in the service). query_args is a JSON blob mirroring the args accepted by buddynext/v1/search; it feeds the buddynext_search_query_args filter for automatic criteria merging.

Column	Type	Notes
id	BIGINT UNSIGNED	Primary key, auto-increment
user_id	BIGINT UNSIGNED	Owner
name	VARCHAR(120)	Saved-search name
query_args	LONGTEXT	JSON query args
created_at	DATETIME	Set on create
last_run_at	DATETIME	Nullable; updated on run

Keys: PRIMARY (id), KEY user_id (user_id, created_at).

Space

Pro does not create a bn_space_meta table. The white-label per-space brand override (meta_key = 'buddynextpro_space_brand', value is a JSON brand blob) is stored in Free’s bn_space_meta table through the space-meta API - Pro never re-creates a Free table (Installer::schema_core() documents this explicitly and omits the CREATE TABLE). Free’s bn_space_meta is WP-meta-shaped (meta_id, bn_space_id, meta_key, meta_value); its columns are documented under Schema: Spaces.

Shared Free tables read or extended by Pro

Several Free-owned tables are read (and in some cases written) by Pro features. They are created and owned by Free’s Installer; Pro never creates or alters them. Their columns are documented under the Free schema pages, and queries against them go through Free services where one exists.

Table	Owner / creator	What Pro does with it
bn_space_meta	Free	Read/write for the white-label per-space brand override via the space-meta API
bn_user_suspensions	Free	Read to extend bulk and auto-suspend flows
bn_appeals	Free	Read and write for the appeal workflow (this is the table the spec called bn_mod_appeals)
bn_space_bans	Free	Read for moderation bulk actions
bn_outbound_webhooks	Free	Pro lifts Free’s 1-endpoint cap via the buddynext_outbound_webhook_limit filter - it does not own the table
bn_outbound_webhook_log	Free	Read for outbound webhook delivery history

Warning: A Pro feature that needs data from one of these tables must read it through the Free service that owns it (for example suspensions and appeals via Free’s moderation services) rather than issuing raw SQL, except where a documented Pro-only read is unavoidable. Pro must never CREATE or ALTER any of these tables.

Notes and gotchas

• Installer is the source of truth, not the manifest snapshot. BuddyNextPro\Core\Installer::schema() creates 18 Pro-owned tables (the six membership tables - tiers, subscriptions, plan-gateway map, invoices, coupons, tax rules; two AI tables - signals and embeddings; push tokens; analytics; four email tables - campaigns, recipients, drip sequences, drip enrollments; mod rules; two label tables; and saved searches). It does not create bn_space_meta - that is a Free table Pro reads/writes via the space-meta API. The manifest dbTables array is a hand-maintained usage index and is not a reliable schema list.
• Additive columns come through maybe_alter_tables(). dbDelta cannot add columns to an existing table reliably, so column back-fills (the membership pricing columns, the signal_type ENUM widening) run as INFORMATION_SCHEMA-guarded ALTER statements that are idempotent on re-run. The back-fill is gated by a buddynextpro_schema_alters version marker so the schema is not probed on every request once converged.
• Pro boots after Free. Pro initializes at plugins_loaded:20 (Free at 15), and Pro’s Installer::maybe_upgrade() runs from Plugin::init() so existing installs pick up new tables and columns on the next boot without a re-activation.
